High Performance Counting Mechanisms

Mechanical engineers are increasingly faced with the challenge of automating strenuous manual work processes.
Particularly the graphics industry demands flexible and easy-to-install counting mechanisms.

Precise
  • Application-optimised
  • Accurate counting, optimised processes
  • Short cycle times, short intervals
Universal

  • From 30 up to 1,100 GSM
    and from 40 up to 900 μm

  • Corner or side edge counting

  • Various installation directions

  • Compact installation dimensions
Gentle
  • Soft counting disc profiles
  • Low immersion depth
  • Low deformation

  • No damages or marks

Individual, appropriate and reliable

We are happy to offer our experience to realise your requirements. This applies both to the design and manufacture of the counting mechanism and to the integration of the counting process into the existing machine control system. This eliminates the need for a separate control system for our counting mechanism. We would be happy to advise you and look forward to receiving your enquiry.

Video

B09

  • Provided with servo motor

  • Utilisation in the destacking process

  • Precise batching of partial layers

  • Remove the last sheet from the pallet

B20

  • Operated using a servo motor provided by the customer

  • Developed for horizontal installation direction

B21

  • Operated using a servo motor provided by the customer

  • Designed for counting small quantities as partial layers

Do you have any questions or need further information? We are happy to assist you.
